1.Control System: Utilized industrial workstation computer in windows control system applying picture type of operation with touch screen to monitor the screw turning speed, injection volume time, injection temperature , mould temperature, movement time and productivity on line, easy to learn and operate.

2.Injection System: The measuring mechanism utilizes potentiometer detection and coordinates with the operation of PLC to control material volume precisely. Driven by linear track, it allows to move speedy and position precisely.

3.Mold Clamping System: Act by toggle mechanism, it opens the mould rapidly. The two-step speedy mould opening/closing mechanism is with detecting device of fully mould closing. Low operation height, high mould opening stroke, can apply to various styles of moulds flexibly. Equipped with hydraulic cylinder, it allows 2mm thickness difference between 2 moulds on one mould station. By fixed mould opening stroke 350mm,it is not affected by any mould thickness changes.

4.Hydraulic System : Reducing noise and upgrading efficiency by applying 3 sets of pump work individually. Precisely control the pressure and flow rate by using proportional valve and computer system.

5.Accessories : No need to water circulation for mould station, using efficient heat insulation material.

6.It’s optional to be equipped with servo system to save energy consumption. It helps to reduce noise, improve work efficiency and reduce hydraulic oil temperature for increasing service life.
